## Introduction

To continue providing maximum reliability and flexibility for all Postgres ClickPipes users, we have now added a toggle to allow creating a logical replication slot with failover enabled. This allows ClickPipes to work seamlessly with high-availability (HA) to preserve replication slots post-failover.

## Background

Postgres has a feature known as [hot standbys](https://www.postgresql.org/docs/current/hot-standby.html) that allows "read replicas" of a Postgres instance to be spun up for querying. Hot standbys recently gained the ability to perform logical decoding (introduced in Postgres 16, released 2023), which allows users to move their CDC workloads off their primary instance. However, this was not enough to unlock high availability for CDC, as any slots created were only for that cluster and not replicated in any manner. In Postgres 17 (released 2024), this was addressed by enabling logical replication failover, which essentially selects slots on the primary instance to be periodically synchronized to one or more standbys in a way that allows logical decoding to resume cleanly after a standby is promoted.

## Why would you want this?

Postgres is quintessentially a "core" database for transaction processing, and that has often necessitated high-availability via standbys (as Postgres is a single-writer design). However, as query workloads diversify, it is becoming increasingly common to replicate data from Postgres to other sources via CDC to leverage their strengths. Until very recently, while Postgres itself was HA, these pipelines were not. Logical replication failover now makes this a reality.

## Process

Although the ClickPipe itself only contains a toggle to enable failover, the entire process of preparing failover slots for use is more complex and has several prerequisites. If you are using Postgres on-premises, you can configure it using the steps below. If you are running Postgres through a managed provider (such as [AWS RDS](https://aws.amazon.com/rds/) or [Google CloudSQL](https://cloud.google.com/sql?hl=en)), you'll need to work with your provider to ensure that the Postgres configuration settings are correctly tuned. Some providers, such as [PlanetScale for Postgres](https://planetscale.com/postgres), already [support](https://planetscale.com/docs/postgres/integrations/logical-cdc#configure-planetscale-cluster-for-failover) this feature as they perform failovers as part of their periodic maintenance.

1.  Your primary and hot standby servers should both be running Postgres 17 or later. Your hot standby should use a physical replication slot to receive changes from the primary (as opposed to WAL archival and restore). Most managed services already set up read replicas in this manner.

2.  To ensure your standbys are set up to handle primary crashes, you should have both [synchronous_standby_names](https://postgresqlco.nf/doc/en/param/synchronous_standby_names/) and [synchronous_commit](https://postgresqlco.nf/doc/en/param/synchronous_commit/) set up so that the primary needs to confirm WAL receipt by a standby before acknowledging a commit, ensuring changes are persisted unless both the primary and standby go down. Again, most managed services already have this setup, but adjustments can be made based on the specific guarantees required.

3.  You need to enable the settings [hot_standby_feedback](https://postgresqlco.nf/doc/en/param/hot_standby_feedback/) and [sync_replication_slots](https://postgresqlco.nf/doc/en/param/sync_replication_slots/) on the standby. sync_replication_slots tells the standby to start a slotsync worker that synchronizes slots from the primary. This setting, in turn, requires hot_standby_feedback for doing this reliably.

4.  You need to add the physical replication slot being used by your hot standby to [synchronized_standby_slots](https://postgresqlco.nf/doc/en/param/synchronized_standby_slots/) on the primary. This ensures that the standbys confirm receipt of WAL containing changes before they're sent on the logical replication slot being used by the ClickPipe. Without this, it's possible that the standby is "behind" the ClickPipe and is unable to resume properly after failover.

5.  When creating the ClickPipe, ensure that you select the option to [create a replication slot with failover enabled](https://clickhouse.com/docs/integrations/clickpipes/postgres/faq#failover-slot).


failover-clickpipes-hq.mp4



6.  After the ClickPipe is created and is in the Running state, query pg_replication_slots on the standby to see a slot starting with mirror_ (the UUID of the slot is the same as the UUID of the ClickPipe). This slot is synced from the primary and has synced and failover set to true. This slot is now ready to use when the standby is promoted.

## Conclusion

The ClickPipes team is hard at work improving our existing connectors while delivering more ways to replicate data to ClickHouse. With support for logical replication failover, users can now confidently rely on Postgres ClickPipes to replicate critical data and gain all the advantages of ClickHouse's query performance for real-time analytics use cases. We also continue to support replicating from hot standbys directly, which can help alleviate some load from the primary for other workloads.

If you'd like to run queries on [ClickHouse Cloud](https://clickhouse.com/cloud) with your data in Postgres, we recommend [ClickPipes for Postgres](https://clickhouse.com/docs/integrations/clickpipes/postgres), which provides reliable, real-time replication without requiring infrastructure management. Self-hosted ClickHouse users should consider [PeerDB](https://github.com/PeerDB-io/peerdb), the battle-hardened CDC tool that powers all Postgres ClickPipes.

Interested in seeing how ClickHouse works on your data? Get started with ClickHouse Cloud in minutes and receive $300 in free credits.

Get started today

Learn about how failover-ready replication slots keep Postgres CDC pipelines running without interruption.






ClickPipes for Postgres now supports failover replication slots

In my opinion, the worst bugs are the ones you decide not to look further into.

Maybe the problem only manifests 2% of the time, or when you run the code on a particular brand of toaster. Maybe the customer doesn't supply enough information to begin narrowing down the cause. Maybe you just don't have enough time to track the issue down fully.

And everyone eventually moves on. But when you see the same bug strike again months later, you quietly mutter to yourself and wish you'd been persistent the first time. This is one of those stories.

The ClickPipes team had encountered a bug with logical replication slot creation on Postgres read replicas—specifically, an issue where a query that was already taking hours rather than the few seconds it usually took couldn’t be terminated by any of the usual methods in Postgres, causing customer frustration and risking the stability of production databases. In this blog post, I’ll walk through how I investigated the problem and ultimately discovered it was due to a Postgres bug. We’ll also share how we fixed it and our experience working with the Postgres community.

## Introduction

At ClickPipes, our charter is simple. Allow customers to easily move lots of data from `<X>` to [ClickHouse](https://clickhouse.com/) Cloud, where X is an ever-growing set of object stores, queues, and databases. My team and I look after the database pipes. But before this, we were a startup named [PeerDB](https://www.peerdb.io/), which made a product that moved lots of data from [Postgres](https://www.postgresql.org/) to `<X>` instead. By being Postgres-focused, the team had significant experience with Postgres CDC at scale.

For the uninitiated, change data capture (CDC) is the process of continuously tracking database changes, allowing ClickPipes to replicate them to ClickHouse in near real-time. Postgres performs change data capture (CDC) primarily through [logical replication](https://www.postgresql.org/docs/current/logical-replication.html) slots. Logical replication slots decode changes from the [write-ahead log](https://www.postgresql.org/docs/current/wal-intro.html) (WAL) and stream them to consumers for replay. They act as an intermediary layer, transforming raw WAL data into consumable change events. The Postgres ClickPipe is built around logical replication, creating slots and using them to read from hundreds of customer databases.

## When it all went awry, seconds before an unkillable query

It all began when one of our biggest PeerDB customers pinged us, letting us know that they had set up a pipe to replicate data from their new Postgres read replica, but it appeared to have become "stuck." Keeping a few possibilities in mind, I pulled up their instance and saw nothing wrong—just a single active connection that was doing… something.

<pre><code type='click-ui' language='sql' show_line_numbers='false'>
SELECT pid,backend_start,xact_start,wait_event_type,wait_event,state,query
FROM pg_stat_activity
WHERE query LIKE '%pg_create_logical_replication_slot%'
AND pid!=pg_backend_pid();
</code></pre>

```
-[ RECORD 1 ]---+--------------------------------------------------------------
pid             | 5074
backend_start   | 2025-06-27 14:57:01.458979+05:30
xact_start      | 2025-06-27 14:57:47.819348+05:30
wait_event_type |
wait_event      |
state           | active
query           | SELECT * FROM pg_create_logical_replication_slot('demo_slot', 'pgoutput');
```

When creating a new pipe, one of the first steps is to create a logical replication slot. This typically takes a few seconds, but it was taking far longer here. We don't see any `wait_event` associated, which means Postgres thinks this command is not stuck waiting on anything. Additionally, we noticed the slot we're trying to create has shown up in the pg_replication_slots system table with an active PID.

After determining that the issue seemed to be on the Postgres side, one of our initial troubleshooting steps was to "turn it off and on again" and reset the pipe so it started afresh. Doing this led to an even more troubling discovery: even though the ClickPipe had disconnected, this rogue command wouldn't go away. We even used [SQL commands](https://www.postgresql.org/docs/current/functions-admin.html#FUNCTIONS-ADMIN-SIGNAL) to send `SIGINT` and `SIGTERM` signals to the backend process assigned to this query, but neither was taking effect. `SIGTERM` not taking effect is *bad* because that's supposed to be the "nuclear" option here.

<pre><code type='click-ui' language='sql' show_line_numbers='false'>
SELECT pg_cancel_backend(5074), pg_terminate_backend(5074);
</code></pre>

```
 pg_cancel_backend | pg_terminate_backend
-------------------+----------------------
 t                 | t
(1 row)
```

<pre><code type='click-ui' language='sql' show_line_numbers='false'>
SELECT pid,wait_event_type,wait_event,state,query
FROM pg_stat_activity
WHERE pid=5074;
</code></pre>


```
 pid  | wait_event_type | wait_event | state  |                             query
------+-----------------+------------+--------+----------------------------------------------------------------
 5074 |                 |            | active | SELECT pg_create_logical_replication_slot('demo_slot', 'pgoutput');
```

We now had a replication slot marked as "active", and since the process connected to the slot refuses to quit, we cannot drop it. The slot was also now beginning to retain WAL for the decoding process, **which is dangerous, as without a way to read from or drop the slot, it can continue retaining WAL indefinitely, risking storage exhaustion**. As the customer was running a managed Postgres service, the only option they had to get out of this situation was to fully restart the Postgres instance to remove this process, which is not a very appealing proposition as it’d lead to downtime for things dependent on it.

As alluded to earlier, this is not the first time we have seen this exact problem. A few months earlier, another customer using a different managed Postgres service saw the same symptoms while creating a few pipes on a read replica. While we were not able to deterministically solve it, tuning some settings (like turning on [`hot_standby_feedback`](https://postgresqlco.nf/doc/en/param/hot_standby_feedback/)) seemed to make it go away, so we attributed it to some idiosyncrasy in their managed service (we now know that this was not the case). But it was worrying to see it in a completely different managed service on the latest Postgres version with all recommended settings. This was when I set aside time to investigate this further.

## Waiting for a COMMIT that never comes

I got my first clue from support for the customer's Postgres provider, which was a `strace` output on the backend process running the broken query:

```
strace: Process 117778 attached
restart_syscall(<... resuming interrupted nanosleep ...>) = 0
nanosleep({tv_sec=0, tv_nsec=1000000}, NULL) = 0
nanosleep({tv_sec=0, tv_nsec=1000000}, NULL) = 0
nanosleep({tv_sec=0, tv_nsec=1000000}, NULL) = 0
nanosleep({tv_sec=0, tv_nsec=1000000}, NULL) = 0
nanosleep({tv_sec=0, tv_nsec=1000000}, NULL) = 0
nanosleep({tv_sec=0, tv_nsec=1000000}, NULL) = 0
...
```

Seeing only `nanosleep` here and no IO or other syscalls would suggest that the backend is in a loop of `sleep()` calls with a constant duration of 1ms each. This was already a good clue since there are only a few places where such a loop exists in Postgres code. After finding a function in the control flow of creating replication slots that could sleep in this manner under certain conditions, I worked backwards to figure out what this function does and what can get it into this state. And while this bug is not that common in production databases, the "reproduction" of this issue is relatively trivial:

1. Either set up or nicely ask a managed service to give you a Postgres cluster (v16+ since that's when standbys started supporting creation of logical replication slots) with a primary instance and a read replica.
2. On the *primary*, start a transaction and perform any DML operation. As an optimization, Postgres only assigns transactions a transactionid/XID once they have written data, so this is to make the transaction "real". Don't COMMIT or ROLLBACK just yet; just leave the session open.
3. On the *read replica*, create a logical replication slot (the most straightforward method would be to use the SQL function [`pg_create_logical_replication_slot`](https://www.postgresql.org/docs/current/functions-admin.html#FUNCTIONS-REPLICATION)). Once you issue the command, Ctrl-C becomes useless. Trying to cancel or terminate the backend from another session doesn't work either. If you read syscalls from the backend process via `strace` or similar, you'd see a lot of `nanosleep` syscalls like the one above.
4. COMMIT/ROLLBACK the transaction from step 2. Doing this will eventually cause the slot creation to return successfully (if you tried to cancel it earlier, it will notice the attempt now and cancel itself).

Internally, creating a replication slot requires waiting for transactions before the slot creation query is issued to COMMIT/ROLLBACK, to reach a "consistent point" where the slot can decode all future transactions. While it is not ideal to have long-running transactions on Postgres for various reasons, the reality is that certain transactions (think reporting queries or large data backfills) can take a while. If we create a slot under these conditions, it will have to wait for transactions to complete and therefore take longer than usual.

```
2025-05-22 10:44:53.868 UTC [1195] LOG:  00000: logical decoding found initial starting point at 0/356B148
2025-05-22 10:44:53.868 UTC [1195] DETAIL:  Waiting for transactions (approximately 1) older than 6068 to end.
```

Since waiting on these older transactions can take an arbitrary amount of time, it is crucial to implement this wait as efficiently as possible. Postgres already handles various locks for different operations, and we can reuse this infrastructure to take a lock on older transactions. Since transactions only release their `transactionid` lock after completing, acquiring this lock confirms that the transaction is done. This approach provides visibility—system tables display active waits, allowing administrators to monitor progress.

<pre><code type='click-ui' language='sql' show_line_numbers='false'>
SELECT pid,wait_event_type,wait_event,state,query
FROM pg_stat_activity
WHERE pid=804;
</code></pre>

```
 pid | wait_event_type |  wait_event   | state  |                             query
-----+-----------------+---------------+--------+----------------------------------------------------------------
 804 | Lock            | transactionid | active | SELECT pg_create_logical_replication_slot('demo_slot', 'pgoutput');
(1 row)
```

<pre><code type='click-ui' language='sql' show_line_numbers='false'>
SELECT locktype,transactionid,pid,mode
FROM pg_locks
WHERE pid=804 AND granted='f';
</code></pre>

```
   locktype    | transactionid | pid |   mode
---------------+---------------+-----+-----------
 transactionid |          6077 | 804 | ShareLock
```

If needed, one can cancel the problematic transactions or the slot creation process that’s still waiting. However, this holds only for a “typical” Postgres instance. As it turns out, being a Postgres read replica breaks some invariants, which leads to different behaviour in the same case.

## Read replicas aren't magic, actually

While "read replica" is the colloquial term for a Postgres instance serving read-only traffic (a term that makes it seem more straightforward than it actually is), Postgres refers to these as "hot standbys". A hot standby is a Postgres instance in "recovery mode" that constantly receives WAL records from a primary Postgres instance and uses these to maintain an exact copy of all data on the primary. The relevant detail here is that the standby can only indirectly observe what transactions running on the primary are doing via the write-ahead log. Specifically, the standby continuously maintains a list of transactions running on the primary known as `KnownAssignedXids` based on information from incoming WAL records.

The function that implements the "wait for a transaction to complete" operation described earlier is named [`XactLockTableWait`](https://github.com/postgres/postgres/blob/483f7246f39b3af250fed1e613d962b85b568861/src/backend/storage/lmgr/lmgr.c#L663), and the crucial part for us is this loop (code simplified for brevity):

```
void
XactLockTableWait(TransactionId xid, Relation rel, ItemPointer ctid,
				  XLTW_Oper oper)
    <...>
	for (;;)
	{
		Assert(TransactionIdIsValid(xid));
		SET_LOCKTAG_TRANSACTION(tag, xid);

		(void) LockAcquire(&tag, ShareLock, false, false);
		LockRelease(&tag, ShareLock, false);

		if (!TransactionIdIsInProgress(xid))
			break;

        	pg_usleep(1000L);
	}
    <...>
```

Postgres acquires a lock on the transaction ID provided as input via `LockAcquire`, which hangs until the transaction completes and releases its lock. After obtaining the lock, we release it immediately and check if the transaction is still in progress via [`TransactionIdIsInProgress`](https://github.com/postgres/postgres/blob/7c319f54917faf564b660fe9027c4835a422bad6/src/backend/storage/ipc/procarray.c#L1402). If it isn't, we exit. However, there is a 1ms sleep before the loop repeats, which we hit if we find the transaction is still running. If we only reach the check after we acquire a lock, how can this happen? As mentioned in a comment within this function, there is a window where the transaction has registered itself as running but hasn't yet acquired its lock on the transactionid. While the code handles this case regardless, the sleep is good for avoiding repeated locking until the transaction reaches a consistent state. Under regular operation, this case should rarely be hit and not for very long.

![User Image (5).png](/uploads/User_Image_5_f945b563ad.png)

Let's now consider the case of a hot standby. A standby still needs to find a consistent point while creating a logical replication slot, and older transactions need to end for that. It isn't the one running the transaction; therefore, the `LockAcquire` will always return immediately on standby. But `TransactionIdIsInProgress` does take `KnownAssignedXids` into account, so we know that the transaction is still running. Thus, we hit the 1ms sleep and then another loop iteration. But unlike earlier, this is not a transient situation; we can be stuck here for hours.

1. The optimized `LockAcquire` wait on the primary is replaced by a fixed 1ms polling loop that wastes cycles if we need to wait a long time.
2. If `LockAcquire` needs to wait, it also handles interrupts. Since the function was designed around waiting in `LockAcquire` and the sleep case is for transient cases, there is no code for handling interrupts within the loop. This is what made the backend process "unkillable".
3. We don't report that we're waiting on an external operation, as `LockAcquire` handled this. The only way a regular user can tell that their slot creation is stuck on this is to look at logs, which still mention the need to wait for older transactions to complete. On a primary, this same wait would be visible in system tables.

This issue is a good example of well-written code causing problems because it was unwittingly roped into handling something it was not designed for. This tends to happen in any codebase of sizable complexity.

## Resolution - allowing an intervention

Our immediate concern was that it was currently impossible to stop a slot creation waiting for a consistent point on a standby. To this effect, I submitted a [patch](https://www.postgresql.org/message-id/flat/CAM45KeELdjhS-rGuvN%3DZLJ_asvZACucZ9LZWVzH7bGcD12DDwg%40mail.gmail.com) to the Postgres mailing list, which just added an interrupt check before each sleep call:

```
+			CHECK_FOR_INTERRUPTS();
 			pg_usleep(1000L);
```

Postgres maintainers quickly [accepted](https://github.com/postgres/postgres/commit/961553daf5d6087b175aa98f3031a46a8666cecf) this patch (thanks, Fujii Masao, for reviewing it!) and backported it to all supported major versions of Postgres. After a minor version upgrade, this problem should be mitigated for all users running hot standbys.

Another community member graciously addressed the issues around the lack of a `wait_event` here and the inefficient loop. A [patch](https://www.postgresql.org/message-id/flat/CABPTF7WZODAVPFxtn9ygA9d6zckkJbFG%3DSUtHdvk7ca%3DUTzSFg%40mail.gmail.com) is out to add a new wait event that highlights this case, and there is also an ongoing discussion about improving the way standbys wait for transactions to complete on the primary. Both these changes are still in flight and should hopefully make it to Postgres 19 next year.

## Lessons learned, and a debt repaid

Once the ClickPipes team understood that this issue was not a one-off case, it took me a day or two to determine the RCA and develop the patch that addresses it. Being familiar with the Postgres codebase, its well-structured nature allowed me to hone in on XactLockTableWait() and work backwards. While the Postgres community has an older and sometimes daunting contribution process of submitting patches to a mailing list, they were also instrumental in reviewing the patch soon and getting it backported, continuing to ensure a high-quality user experience.

This investigation into a seemingly simple bug reveals the incredible depth and complexity that lie beneath the surface of modern database systems. Postgres, with decades of development and its battle-tested architecture, still harbors edge cases where different subsystems can interact with each other in unexpected ways. Similarly, ClickHouse, with its columnar storage engine and rich feature set, also presents fascinating challenges in pushing the boundaries of analytical performance. As both databases are open source, it’s easier to identify issues like this, fix them, and submit your patches upstream, repaying your debt to a system that has served you well.

Replicating data from PostgreSQL to ClickHouse unlocks columnar storage performance, parallel query execution, and advanced time-series analytics, enabling workloads that would be impractical or impossible on row-based transactional systems. We recommend [ClickPipes for Postgres](https://clickhouse.com/docs/en/integrations/clickpipes/postgres) for ClickHouse Cloud users, offering managed real-time replication with zero infrastructure overhead. Self-hosted ClickHouse users should consider [PeerDB](https://github.com/PeerDB-io/peerdb), which provides high-performance self-hosted CDC capabilities. Both solutions work seamlessly with Postgres read replicas for CDC operations, allowing you to offload replication traffic from your primary database.
