One of the main selling points of ClickHouse is that it's very fast, in many cases utilizing the hardware up to the theoretical limits. This speed boils down to a right combination of architectural choices and algorithmic optimizations.






Testing the Performance of ClickHouse

Code review is one of the few software development techniques that are consistently found to reduce the incidence of defects. Why is it effective? This article offers some wild conjecture on this topic, complete with practical advice on getting the most out of your code review.


## Understanding Why Your Program Works

As software developers, we routinely have to reason about the behaviour of software. For example, to fix a bug, we start with a test case that exhibits the behavior in question, and then read the source code to see how this behavior arises. Often we find ourselves unable to understand anything, having to resort to forensic techniques such as using a debugger or interrogating the author of the code. This situation is far from ideal. After all, if we have trouble understanding our software, how can we be sure it works at all? No surprise that it doesn't.

The correct understanding is also important when modifying and extending software. A programmer must always have a precise mental model on what is going on in the program, how exactly it maps to the domain, and so on. If there are flaws in this model, the code they write won't match the domain and won't solve the problem correctly. Wrong understanding directly causes bugs.

How can we make our software easier to understand? It is often said that to see if you really understand something, you have to try explaining it to somebody. For example, as a science student taking an exam, you might be expected to give an explanation to some well-known observed effect, deriving it from the basic laws of this domain. In a similar way, if we are modeling some problem in software, we can start from domain knowledge and general programming knowledge, and build an argument as to why our model is applicable to the problem, why it is correct, has optimal performance and so on. This explanation takes the form of code comments, or, at a higher level, design documents.

If you have a habit of thoroughly commenting your code, you might have noticed that writing the comments is often much harder than writing the code itself. It also has an unpleasant side effect &mdash; at times, while writing a comment, it becomes increasingly clear to you that the code is incomprehensible and takes forever to explain, or maybe is downright wrong, and you have to rewrite it. This is exactly the major positive effect of writing the comments. It helps you find bugs and make the code more understandable, and you wouldn't have noticed these problems unless you tried to explain the code.

Understanding why your program works is inseparable from understanding why it fails, so it's no surprise that there is a similar process for the latter, called "rubber duck debugging". To debug a particularly nasty bug, you start explaining the program logic step by step to an imaginary partner or even to an inanimate object such as a yellow rubber duck. This process is often very effective, much in excess of what one would expect given the limited conversational abilities of rubber ducks. The underlying mechanism is probably the same as with comments &mdash; you start to understand your program better by just trying to explain it, and this lets you find bugs.

When working in a team, you even have a luxury of explaining your code to another developer who works on the same project. It's probably more entertaining than talking to a duck. More importantly, they are going to maintain the code you wrote, so better make sure that _they_ can understand it as well. A good formal occasion for explaining how your code works is the code review process. Let's see how you can get the most out of it, in terms of making your code understandable.

## Reviewing Others Code

Code review is often framed as a gatekeeping process, where each contribution is vetted by maintainers to ensure that it is in line with project direction, has acceptable quality, meets the coding guidelines and so on. This perspective might seem natural when dealing with external contributions, but makes less sense if you apply it to internal ones. After all, our fellow maintainers have perfect understanding of project goals and guidelines, probably they are more talented and experienced than us, and can be trusted to produce the best solution possible. How can an additional review be helpful?

A less-obvious, but very important, part of reviewing the code is just seeing whether it can be understood by another person. It is helpful regardless of the administrative roles and programming proficiency of the parties. What should you do as a reviewer if ease of understanding is your main priority?

You probably don't need to be concerned with trivia such as code style. There are automated tools for that. You might find some bugs, but this is probably a side effect. Your main task is making sense of the code.

Start with checking the high-level description of the problem that the pull request is trying to solve. Read the description of the bug it fixes, or the docs for the feature it adds. For bigger features, there is normally a design document that describes the overall implementation without getting too deep into the code details. After you understand the problem, start reading the code. Does it make sense to you? You shouldn't try too hard to understand it. Imagine that you are tired and under time pressure. If you feel you have to make a lot of effort to understand the code, ask the author for clarifications. As you talk, you might discover that the code is not correct, or it may be rewritten in a more straightforward way, or it needs more comments.

![hidden-items.png](/uploads/hidden_items_b1aba22fb2.png)

After you get the answers, don't forget to update the code and the comments to reflect them. Don't just stop after getting it explained to you personally. If you had a question as a reviewer, chances are that other people will also have this question later, but there might be nobody around to ask. They will have to resort to `git blame` and re-reading the entire pull request or several of them. Code archaeology is sometimes fun, but it's the last thing you want to do when you are investigating an urgent bug. All the answers should be on the surface.

Working with the author, you should ensure that the code is mostly obvious to anyone with basic domain and programming knowledge, and all non-obvious parts are clearly explained.

### Preparing Your Code For Review

As an author, you can also do some things to make your code easier to understand for the reviewer.

First of all, if you are implementing a major feature, it probably needs a round of design review before you even start writing code. Skipping a design review and jumping right into the code review can be a major source of frustration, because it might turn out that even the problem you are solving was formulated incorrectly, and all your work has to be thrown away. Of course, this is not prevented completely by design review, either. Programming is an iterative, exploratory activity, and in complex cases you only begin to grasp the problem after implementing a first solution, which you then realize is incorrect and has to be thrown away.

When preparing your code for review, your major objective is to make your problem and its solution clear to the reviewer. A good tool for this is code comments. Any sizable piece of logic should have an introductory comment describing its general purpose and outlining the implementation. This description can reference similar features, explain the difference to them, explain how it interfaces with other subsystems. A good place to put this general description is a function that serves as a main entry point for the feature, or other form of its public interface, or the most significant class, or the file containing the implementation, and so on.

Drilling down to each block of code, you should be able to explain what it does, why it does that, why this way and not another. If there are several ways of doing the thing, why did you choose this one? Of course, for some code these things follow from the more general comments and don't have to be restated. The mechanics of data manipulation should be apparent from the code itself. If you find yourself explaining a particular feature of the language, it's probably best not to use it.

Pay special attention to making the data structures apparent in the code, and their meaning and invariants well commented. The choice of data structures ultimately determines which algorithms you can apply, and sets the limits of performance, which is another reason why we should care about it as ClickHouse developers.

When explaining the code, it is important to give your reader enough context, so that they can understand you without a deep investigation of the surrounding systems and obscure test cases. Give pointers to all the things that might be relevant to the task. If you know some corner cases which your code has to handle, describe them in enough detail so that they can be reproduced. If there is a relevant standard or a design document, reference it, or even quote it inline. If you're relying on some invariant in other system, mention it. It is good practice to add programmatic checks that mirror your comments, when it is easy to do so. Your comment about an invariant should be accompanied by an assertion, and an important scenario should be reproduced by a test case.

Don't worry about being too verbose. There is often not enough comments, but almost never too much of them.

## Common Concerns about Code Comments

It is common to hear objections to the idea of commenting the code, so let's discuss a couple of usual ones.

### Self-documenting Code

You can often see a perplexing idea that the source code can somehow be "self-documenting", or that the comments are a "code smell", and their presence indicates that the code is badly written. I have trouble imagining how this belief can be compatible with any experience in maintaining sufficiently complex and large software, over the years, in collaboration with others. The code and the comments describe different parts of the solution. The code describes the data structures and their transformations, but it cannot convey meaning. The names in the code serve as pointers that map the data and its transformations to the domain concepts, but they are schematic and lack nuance. It is not so difficult to write code that makes it easy to understand what's going on in terms of data manipulation. What it takes is mostly moderation, that is, stopping yourself from being too clever. For most code, it is easy to see what it does, but why? Why this way and not that way? Why is it correct? Why this fast path here helps? Why did you choose this data layout? How is this invariant guaranteed? And so on. This might be not so evident for a developer who is working alone on a short-lived project, because they have all the necessary context in their head. But when they have to work with other people (or even with themselves from past and future), or in an unfamiliar area, the importance of non-code, higher-level context becomes painfully clear. The idea that we should, or even can, somehow encode comments such as [this one](https://github.com/ClickHouse/ClickHouse/blob/26d5db32ae5c9f54b8825e2eca1f077a3b17c84a/src/Storages/MergeTree/KeyCondition.cpp#L1312-L1347) into names or control flow is just absurd.

### Obsolete Comments

The comments can't be checked by the compiler or the tests, so there is no automated way to make sure that they are up to date with the rest of the comments and the code. The possibility of comments gradually getting incorrect is sometimes used as an argument against having any comments at all.

This problem is not exclusive to the comments &mdash; the code also can and does become obsolete. Simple cases such as dead code can be detected by static analysis or studying the test coverage of code. More complex cases can only be found by proofreading, such as maintaining an invariant that is not important anymore, or preparing some data that is not needed.

While an obsolete comment can lead to a mistake, the same applies, perhaps more strongly, to the lack of comments. When you need some higher-level knowledge about the code, but it is not written down, you are forced to perform an entire investigation from first principles to understand what's going on, and this is error-prone. Even an obsolete comment likely gives a better starting point than nothing. Moreover, in a code base that makes an active use of the comments, they tend to be mostly correct. This is because the developers rely on comments, read and write them, pay attention to them during code review. The comments are routinely changed along with changing the code, and the outdated comments are soon noticed and fixed. This does require some habit. A lone comment in a vast desert of impenetrable self-documenting code is not going to fare well.


## Conclusion

Code review makes your software better, and a significant part of this probably comes from trying to understand what your software actually does. By paying attention specifically to this aspect of code review, you can make it even more efficient. You'll have less bugs, and your code will be easier to maintain &mdash; and what else could we ask for as software developers?


_2021-04-13 [Alexander Kuzmenkov](https://github.com/akuzm). Title photo by [Nikita Mikhaylov](https://github.com/nikitamikhaylov)_

_P.S. This text contains the personal opinions of the author, and is not an authoritative manual for ClickHouse maintainers._

Code review is one of the few software development techniques that are consistently found to reduce the incidence of defects.






The Tests Are Passing, Why Would I Read The Diff Again?

Testing is a major problem in software development: there is never enough of it. It becomes especially true for a database management system, whose task is to interpret a query language that works on the persistent state managed by the system in a distributed fashion. Each of these three functions is hard enough to test even in isolation, and it gets much worse when you combine them. As ClickHouse developers, we know this from experience. Despite a large amount of automated testing of all kinds we routinely perform as part of our continuous integration system, new bugs and regressions are creeping in. We are always looking for the ways to improve our test coverage, and this article will describe our recent development in this area &mdash; the AST-based query fuzzer.

## How to Test a SQL DBMS

A natural form of testing for a SQL DBMS is to create a SQL script describing the test case, and record its reference result. To test, we run the script and check that the result matches the reference. This is used in many SQL DBMS, and it is the default kind of a test you are expected to write for any ClickHouse feature or fix. Currently we have [73k lines of SQL tests alone](https://github.com/ClickHouse/ClickHouse/tree/master/tests/queries/0_stateless), that reach the [code coverage of 76%](https://clickhouse-test-reports.s3.yandex.net/0/47d684a5c35410201d4dd4f63f3287bf25cdabb7/coverage_report/test_output/index.html).

This form of testing, where a developer writes a few simplified examples of how the feature can and cannot be used, is sometimes called "example-based testing". Sadly, the bugs often appear in various corner cases and intersections of features, and it is not practical to enumerate all of these cases by hand. There is a technique for automating this process, called "property-based testing". It lets you write more general tests of the form "for all values matching these specs, the result of some operation on them should match this other spec". For example, such a test can check that if you add two positive numbers, the result is greater than both of them. But you don't specify which numbers exactly, only these properties. Then, the property testing system randomly generates some examples with particular numbers that match the specification, and checks that the result also matches its specification.

Property-based testing is said to be very efficient, but requires some developer effort and expertise to write the tests in a special way. There is another well-known testing technique that is in some sense a corner case of property-based testing, and that doesn't require much developer time. It is called fuzzing. When you are fuzzing your program, you feed it random inputs generated according to some grammar, and the property you are checking is that your program terminates correctly (no segfaults or assertions or other kinds of program errors). Most often, the grammar of input for fuzzing is simple &mdash; say, bit flips and additions, or maybe some dictionary. The space of possible inputs is huge, so to find interesting paths in it, fuzzing software records the code paths taken by the program under test for a particular input, and focuses on the inputs that lead to new code paths that were not seen before. It also employs some techniques for finding interesting constant values, and so on. In general, fuzzing allows you to find many interesting corner cases in your program automatically, without much developer involvement.

Generating valid SQL queries with bit flips would take a long time, so there are systems that generate queries based on the SQL grammar, such as [SQLSmith](https://github.com/anse1/sqlsmith).  They are succesfully used for finding bugs in databases. It would be interesting to use such a system for ClickHouse, but it requires some up-front effort to support the ClickHouse SQL grammar and functions, which may be different from the standard. Also, such systems don't use any feedback, so while they are much better than systems with primitive grammar, they still might have a hard time finding interesting examples. But we already have a big corpus of human-written interesting SQL queries &mdash; it's in our regression tests. Maybe we can use them as a base for fuzzing? We tried to do this, and it turned out to be surprisingly simple and efficient.

## AST-based Query Fuzzer

Consider some SQL query from a regression test. After parsing, it is easy to mutate the resulting AST (abstract syntax tree, an internal representation of the parsed query) before execution to introduce random changes into the query.  For strings and arrays, we make random modifications such as inserting a random character or doubling the string. For numbers, there are well-known Bad Numbers such as 0, 1, powers of two and nearby, integer limits, `NaN`. `NaN`s proved to be especially efficient in finding bugs, because you can often have some alternative branches in your numeric code, but for a `NaN`, both branches hold (or not) simultaneously, so this leads to nasty effects.

Another interesting thing we can do is change the arguments of functions, or the list of expressions in `SELECT`, `ORDER BY` and so on. Naturally, all the interesting arguments can be taken from other test queries. Same goes for changing the tables used in the queries. When the fuzzer runs in CI, it runs queries from all the SQL tests in random order, mixing into them some parts of queries it has seen previously. This process can eventually cover all the possible permutations of our features.

The core implementation of the fuzzer is relatively small, consisting of about 700 lines of C++ code. A prototype was made in a couple of days, but naturally it took significantly longer to polish it and to start routinely using it in CI. It is very productive and let us find more than 200 bugs already (see the label [fuzz](https://github.com/ClickHouse/ClickHouse/labels/fuzz) on GitHub), some of which are serious logic errors or even memory errors. When we only started, we could segfault the server or make it enter a never-ending loop with simplest read-only queries such as `SELECT arrayReverseFill(x -> (x < 10), [])` or `SELECT geoDistance(0., 0., -inf, 1.)`. Of course I couldn't resist bringing down our [public playground](https://gh-api.clickhouse.com/play?user=play#LS0gWW91IGNhbiBxdWVyeSB0aGUgR2l0SHViIGhpc3RvcnkgZGF0YSBoZXJlLiBTZWUgaHR0cHM6Ly9naC5jbGlja2hvdXNlLnRlY2gvZXhwbG9yZXIvIGZvciB0aGUgZGVzY3JpcHRpb24gYW5kIGV4YW1wbGUgcXVlcmllcy4Kc2VsZWN0ICdoZWxsbyB3b3JsZCc=) with some of these queries, and was content to see that the server soon restarts correctly.  These queries are actually minified by hand, normally the fuzzer would generate something barely intelligible such as:
```sql
SELECT
    (val + 257,
      (((tuple(NULL), 10.000100135803223), tuple(-inf)), '-1', (NULL, '0.10', NULL), NULL),
      (val + 9223372036854775807) = (rval * 100),
      tuple(65535), tuple(NULL), NULL, NULL),
    *
FROM
(
    SELECT dummy AS val
    FROM system.one
) AS s1
ANY LEFT JOIN
(
    SELECT toLowCardinality(toNullable(dummy)) AS rval
    FROM system.one
) AS s2 ON (val + 100) = (rval * 7)
```
In principle, we could add automated test case minification by modifying AST in the same vein with fuzzing. This is somewhat complicated by the fact that the server dies after every, excuse my pun, successfully failed query, so we didn't implement it yet.

Not all errors the fuzzer finds are significant, some of them are pretty boring and harmless, such as a wrong error code for an out-of-bounds argument. We still try to fix all of them, because this lets us ensure that under normal operation, the fuzzer doesn't find any errors.  This is similar to the approach usually taken with compiler warnings and other optional diagnostics &mdash; it's better to fix or disable every single case, so that you can be sure you have no diagnostics if everything is OK, and it's easy to notice new problems.

After fixing the majority of pre-existing error, this fuzzer became efficient for finding errors in new features. Pull requests introducing new features normally add an SQL test, and we pay extra attention to the new tests when fuzzing, generating more permutations for them. Even if the coverage of the test is not sufficient, there is a good chance that the fuzzer will find the missing corner cases. So when we see that all the fuzzer runs in different configurations have failed for a particular pull request, this almost always means that it introduces a new bug. When developing a feature that requires new grammar, it is also helpful to add fuzzing support for it. I did this for window functions early in the development, and it helped me find several bugs.

A major factor that makes fuzzing really efficient for us is that we have a lot of assertions and other checks of program logic in our code. For debug-only checks, we use the plain `assert` macro from `<cassert>`. For checks that are needed even in release mode, we use an exception with a special code `LOGICAL_ERROR` that signifies an internal program error. We did some work to ensure that these errors are distinct from errors caused by the wrong user actions. A user error reported for a randomly generated query is normal (e.g.  it references some non-existent columns), but when we see an internal program error, we know that it's definitely a bug, same as an assertion. Of course, even without assertions, you get some checks for memory errors provided by the OS (segfaults). Another way to add runtime checks to your program is to use some kind of sanitizer. We already run most of our tests under clang's Address, Memory, UndefinedBehavior and Thread sanitizers. Using them in conjunction with this fuzzer also proved to be very efficient.

To see for yourself how the fuzzer works, you only need the normal ClickHouse client.  Start `clickhouse-client --query-fuzzer-runs=100`, enter any query, and enjoy the client going crazy and running a hundred of random queries instead. All queries from the current session become a source for expressions for fuzzing, so try entering several different queries to get more interesting results. Be careful not to do this in production! When you do this experiment, you'll soon notice that the fuzzer tends to generate queries that take very long to run. This is why for the CI fuzzer runs we have to configure the server to limit query execution time, memory usage and so on using the corresponding [server settings](/docs/en/operations/settings/query-complexity/#:~:text=In%20the%20default%20configuration%20file,query%20within%20a%20single%20server.). We had a hilarious situation after that: the fuzzer figured out how to remove the limits by generating a `SET max_execution_time = 0` query, and then generated a never-ending query and failed. Thankfully we were able to defeat its cleverness by using [settings constraints](/docs/en/operations/settings/constraints-on-settings/).

## Other Fuzzers

The AST-based fuzzer we discussed is only one of the many kinds of fuzzers we have in ClickHouse. There is a [talk](https://www.youtube.com/watch?v=GbmK84ZwSeI&t=4481s) (in Russian, [slides are here](https://presentations.clickhouse.com/cpp_siberia_2021/)) by Alexey Milovidov that explores all the fuzzers we have. Another interesting recent development is application of pivoted query synthesis technique, implemented in [SQLancer](https://github.com/sqlancer/sqlancer), to ClickHouse.  The authors are going to give [a talk about this](https://heisenbug-piter.ru/2021/spb/talks/nr1cwknssdodjkqgzsbvh/) soon, so stay tuned.

_2021-03-11 [Alexander Kuzmenkov](https://github.com/akuzm)_


We are always looking for the ways to improve our test coverage, and this article will describe our recent development in this area — the AST-based query fuzzer.






Fuzzing ClickHouse

This is a brief description of my experiments with building ClickHouse on Android. If this is your first time hearing about ClickHouse, it is a suriprisingly fast columnar SQL DBMS for real-time reporting. It's normally used in AdTech and the like, deployed on clusters of hundreds of machines, holding up to petabytes of data. But ClickHouse is straightforward to use on a smaller scale as well &mdash; you laptop will do, and don't be surprised if you are able to process several gigabytes of data per second on this hardware. There is another kind of small-scale, though pretty powerful, platforms, that is ubiquitous now &mdash; smartphones. The conclusion inevitably follows: you must be able to run ClickHouse on your smartphone as well. It's also that I can't help but chuckle at the idea of setting up a high performance mobile OLAP cluster using a dozen of phones. Or also at the idea of seeing the nostalgic `Segmentation fault (core dumped)` on the lovely OLED screen, but I digress. Let's get it going.

## First cheap attempt

I heard somewhere that Android uses the Linux kernel, and I can already run familiar UNIX-like shell and tools using [Termux](https://termux.com/). And ClickHouse already supports ARM platform and even publishes a binary built for 64-bit ARM. This binary also doesn't have a lot of dependencies &mdash; only a pretty old version of `glibc`. Maybe I can just download a ClickHouse binary from CI to the phone and run it?

Turns out it's not that simple.

* The first thing we'll see after trying to run is an absurd error message: `./clickhouse: file is not found`. But it's right there! `strace` helps: what cannot be found is `/lib64/ld-linux-x86-64.so.2`, a linker specified in the ClickHouse binary. The linker, in this case, is a system program that initially loads the application binary and its dependencies before passing control to the application. Android uses a different linker located by another path, this is why we get the error. This problem can be overcome if we call the linker explicitly, e.g. `/system/bin/linker64 $(readlink -f ./clickhouse)`.

* Immediately we encounter another problem: the linker complains that the binary has a wrong type `ET_EXEC`. What does this mean? Android binaries must support dynamic relocation, so that they can be loaded at any address, probably for ASLR purposes. ClickHouse binaries do not normally use position-independent code, because we have measured that it gives a small performance penalty of about 1%. After tweaking compilation and linking flags to include `-fPIC` as much as possible, and battling some really weird linker errors, we finally arrive at a relocatable binary that has a correct type `ET_DYN`.

* But it only gets worse. Now it complains about TLS section offset being wrong. After reading some mail archives where I could barely understand a word, I concluded that Android uses some different layout of memory for the section of the executable that holds thread-local variables, and `clang` from Android toolchain is patched to account for this. After that, I had to accept I won't be able to use familiar tools, and reluctantly turned to the Android toolchain.

## Using the Android toolchain

Surprisingly, it's rather simple to set up. Our build system uses CMake and already supports cross-compilation &mdash; we have CI configurations that cross-compile for Mac, AArch64 Linux and FreeBSD. Android NDK also has integration with CMake and a [manual](https://developer.android.com/ndk/guides/cmake) on how to set it up. Download the Android NDK, add some flags to your `cmake` invocation: `DCMAKE_TOOLCHAIN_FILE=~/android-ndk-r21d/build/cmake/android.toolchain.cmake -DANDROID_ABI=arm64-v8a -DANDROID_PLATFORM=28`, and you're done. It (almost) builds. What obstacles do we have this time?

* Our `glibc` compatibility layer has a lot of compilation errors. It borrows `musl` code to provide functions that are absent from older versions of `glibc`, so that we can run the same binary on a wide range of distros. Being heavily dependent on system headers, it runs into all kinds of differences between Linux and Android, such as the limited scope of `pthread` support or just subtly different API variants. Thankfully we're building for a particular version of Android, so we can just disable this and use all needed functions straight from the system `libc`.
* Some third-party libraries and our CMake files are broken in various unimaginative ways. Just disable everything we can and fix everything we can't.
* Some of our code uses `#if defined(__linux__)` to check for Linux platform. This doesn't always work, because Android also exports `__linux__` but there are some API differences.
* `std::filesystem` is still not fully supported in NDK r21. The support went into r22 that is scheduled for Q3 2020, but I want it right now... Good that we bundle our own forks of `libcxx` and `libcxxabi` to reduce dependencies, and they are fresh enough to fully support C++20. After enabling them, everything works.
* Weird twenty-screens errors in `std::map<int>` or something like that, that are also resolved by using our `libcxx`.

## On the device

At last, we have a binary we can actually run. Copy it to  the phone, `chmod +x`, `./clickhouse server --config-path db/config.xml`, run some queries, it works!

![segfault.jpg](/uploads/segfault_85391a0670.jpg)

Feels so good to see my favorite message.

It's a full-fledged development environment here in Termux, let's install `gdb` and attach it to see where the segfault happens. Run `gdb clickhouse --ex run '--config-path ....'`, wait for it to lauch for a minute, only to see how Android kills Termux becase it is out of memory. Are 4 GB of RAM not enough, after all? Looking at the `clickhouse` binary, its size is a whoppping 1.1 GB. The major part of the bloat is due to the fact that some of our computational code is heavily specialized for particular data types (mostly via C++ templates), and also the fact that we build and link a lot of third-party libraries statically. A non-essential part of the binary is debug symbols, which help to produce good stack traces in error messages. We can remove them with `strip -s ./clickhouse` right here on the phone, and after that, the size becomes more manageable, about 400 MB. Finally we can run `gdb` and see that the segfault is somewhere in `unw_backtrace`:

```
Thread 60 "ConfigReloader" received signal SIGSEGV, Segmentation fault.
[Switching to LWP 21873]
0x000000556a73f740 in ?? ()

(gdb) whe 20
#0  0x000000556a73f740 in ?? ()
#1  0x000000556a744028 in ?? ()
#2  0x000000556a73e5a0 in ?? ()
#3  0x000000556a73d250 in unw_init_local ()
#4  0x000000556a73deb8 in unw_backtrace ()
#5  0x0000005562aabb54 in StackTrace::tryCapture() ()
#6  0x0000005562aabb10 in StackTrace::StackTrace() ()
#7  0x0000005562a8d73c in MemoryTracker::alloc(long) ()
#8  0x0000005562a8db38 in MemoryTracker::alloc(long) ()
#9  0x0000005562a8e8bc in CurrentMemoryTracker::alloc(long) ()
#10 0x0000005562a8b88c in operator new[](unsigned long) ()
#11 0x0000005569c35f08 in Poco::XML::NamePool::NamePool(unsigned long) ()
...
```

What is this function, and why do we need it? In this particular stack trace, we're out of memory, and about to throw an exception for that. `unw_backtrace` is called to produce a backtrace for the exception message. But there is another interesting context where we call it. Believe it or not, ClickHouse has a built-in `perf`-like sampling profiler that can save stack traces for CPU time and real time, and also memory allocations. The data is saved into a `system.trace_log` table, so you can build flame graphs for what your query was doing as simple as piping output of an SQL query into `flamegraph.pl`. This is an interesting feature, but what is relevant now is that it sends signals to all threads of the server to interrupt them at some random time and save their current backtraces, using the same `unw_backtrace` function that we know to segfault. We expect query profiler to be used in production environment, so it is enabled by default. After disabling it, we have a functioning ClickHouse server running on Android.

## Is your phone good enough?

There is a beaten genre of using data sets and queries of a varying degree of syntheticity to prove that a particular DBMS you work on has performance superior to other, less advanced, DBMSes. We've moved past that, and instead use the DBMS we love as a benchmark of hardware. For this benchmark we use a small 100M rows obfuscated data set from Yandex.Metrica, about 12 GB compressed, and some queries representative of Metrica dashboards. There is [this page](/benchmark/hardware/) with crowdsourced results for various cloud and traditional servers and even some laptops, but how do the phones compare? Let's find out. Following [the manual](/docs/en/operations/performance-test/) to download the necessary data to the phone and run the benchmark was pretty straightforward. One problem was that some queries can't run because they use too much memory and the server gets killed by Android, so I had to script around that. Also, I'm not sure how to reset a file system cache on Android, so the 'cold run' data is not correct. The results look pretty good:

![compare.jpg](/uploads/compare_6250c74c7c.jpg)

My phone is Google Pixel 3a, and it is only 5 times slower on average than my Dell XPS 15 work laptop. The queries where the data doesn't fit into memory and has to go to disk (the flash, I mean) are noticeably slower, up to 20 times, but mostly they don't complete because the server gets killed &mdash; it only has about 3 GB of memory available. Overall I think the results look pretty good for the phone. High-end models should be even more performant, reaching performance comparable to some smaller laptops.

## Conclusion

This was a rather enjoyable exercise. Running a server on your phone is a nice way to give a demo, so we should probably publish a Termux package for ClickHouse. For this, we have to debug and fix the `unw_backtrace` segfault (I have my fingers crossed that it will be gone after adding `-fno-omit-frame-pointer`), and also fix some quirks that are just commented out for now. Most of the changes required for the Android build are already merged into our master branch.

Building for Android turned out to be relatively simple &mdash; all these experiments and writing took me about four days, and it was the first time I ever did any Android-related programming. The NDK was simple to use, and our code was cross-platform enough so I only had to make minor modifications. If we didn't routinely build for AArch64 and had a hard dependency on SSE 4.2 or something, it would have been a different story.

But the most important takeout is that now you don't have to obsess over choosing a new phone &mdash; just benchmark it with ClickHouse.


_2020-07-16 [Alexander Kuzmenkov](https://github.com/akuzm)_
